AS241D high temperature and high pressure dyeing machine is suitable for dyeing and pre-treatment and after-treatmen of polyester and blended fiber cheese under high temperature conditions; it is also suitable for dyeing and pre-treatment and after-treatment of cotton, linen, acrylic, wool and other fibers under normal temperature conditions.
Other forms of fibers, such as slivers, hank, soft cheese, bulk fiber, cakes (viscose), nylon zipper, ticking buckle, wrap yarn also can be dyed and treated by changing the different dyeing carriers.
Technical parameters
Design pressure : 0.44Mpa
Maximum working pressure : 0.4Mpa
Design temperature : 140°C
Maximum working temperature : 135°C
Heating rate : 20°C ~ 130°C about 35 minutes ( Saturated vapor pressure : 0.7Mpa )
Cooling rate : 130°C ~ 80°C about 25 minutes ( Cooling water pressure : 0.3Mpa ) ( Cooling water Temperature : 5°C~ 10°C)
Liquid ratio : 1:5-1:6
Other forms of fibers, such as slivers, hank, soft cheese, bulk fiber, cakes (viscose), nylon zipper, ticking buckle, wrap yarn also can be dyed and treated by changing the different dyeing carriers.
Technical parametersDesign pressure : 0.44Mpa
Maximum working pressure : 0.4Mpa
Design temperature : 140°C
Maximum working temperature : 135°C
Heating rate : 20°C ~ 130°C about 35 minutes ( Saturated vapor pressure : 0.7Mpa )
Cooling rate : 130°C ~ 80°C about 25 minutes ( Cooling water pressure : 0.3Mpa ) ( Cooling water Temperature : 5°C~ 10°C)
Liquid ratio : 1:5-1:6
